    Building Integrated Photovoltaics

    Residential BIPV Solar Modules | Double Glass Design for Roof & Facade Integration

    Electrical Performance Parameters

    Model

    603*603*50mm(Sizes can be customized)

    Norminal Power

    52W(Different colors result in differences in power)

    Voc

    58.0V

    Isc

    1.39A

    Vm

    43.2V

    Im

    1.22A

    Weight

    double glass 7kg / pcs、triple glass 10kg / pcs(Different structures, sizes, and weights)

    Thickness

    6.9mm、11mm

    Composition

    3.2mm Power glass + 0.5mm + 3.2mm Float glass (with Aluminum frame)

    3.2mm Ultra clear glass + 0.76mm + 3.2mm Power glass + 0.76mm + 3.2mm Float glass (with Aluminum frame)

    Product Color

    Black, blue, red, gold, silver, green, gray, etc

    Waterproofing Method

    Structural overlap waterproofing

    Power Temperature Coefficient

    -0.214% / °C

    Voltage Temperature Coefficient

    -0.321% / °C

    Current Temperature Coefficient

    0.060% / °C

    Product Features

    Describe

    PV Square Tile

    Grunsolar’s PV Tile series, a revolutionary work in architectural aesthetics and photovol- taic technologyl Not only as an efficient power generation component, but also leading the new trend of building rooftop PV with excellent integrity, durability, safety, and

    waterproof performance. PV Tile has a service life of over 25 years, significant economic benefits, and a much higher return on investment than traditional building materials. PV Tile has excellent thermal insulation performance and saves energy costs. It is easy and efficient to install greatly reducing construction costs. At the same time, it has high

    installed capacity and top-notch power generation efficiency, with rich and diverse colors to meet personalized needs.

    菱瓦 304 WH 800x600px

    Project

    Application Scenarios

    Our aim is to serve the global market through localized production and a global supply chain, helping customers achieve their carbon reduction goals.
