    HomeProductsResidential & Commercial StorageResidential Energy Storage System (ESS)-GRWL-16
    Residential & Commercial Storage

    Residential Energy Storage System (ESS)-GRWL-16

    Parameter Specification
    Model GRWL-16
    Total Energy 16.08 kWh
    Usable Energy 14.47 kWh
    Size (W × D × H) 564 × 157 × 974 mm
    Weight 126 kg
    Nominal Voltage 51.2 V
    Voltage Range 48 – 56 V
    Max. Discharge Power 10 kW
    Communication Method CAN / RS485
    Parallel Support (Maximum) Up to 8 in parallel
    Protection Mode Multiple Protection
    Battery Type LFP (LiFePO4)
    Capacity 314 Ah
    IP Level IP20
    Battery Protection Over-Current / Over-Voltage / Short Circuit / Under-Voltage / Over-Temperature
    Protective Class I
    Charge Operating Temperature -10 to 70 °C
    Discharge Operating Temperature -20 to 70 °C
    Humidity 0 – 95% RH (non-condensing)
    Altitude ≤2000m

    Inquire Now

    Download

    Share:

    Product Features

    • 01

      Advanced Smart BMS: Multi-inverter compatibility and scalable parallel expansion up to 8 units.

    • 02

      Smart Connectivity: Integrated Wi-Fi for OTA upgrades and full system monitoring.

    • 03

      Proven Safety: LFP chemistry + 14 protection strategies for reliable indoor operation.

    • 04

      Cost-Effective Design: Compact, minimalist form with easy installation and competitive pricing.

    Describe

    The GRWL-16 is a high-performance, cost-effective indoor residential energy storage solution engineered to maximize solar self-consumption, deliver reliable backup power, and integrate seamlessly with home renewable energy setups. With a total capacity of 16.08 kWh (14.47 kWh usable) and a 10 kW maximum discharge power, this floor/wall-mountable system balances advanced smart technology, robust safety, and flexible scalability for modern households.

    At its core, Leading Technology powers the GRWL-16 via an Advanced Smart Battery Management System (BMS) that supports multi-brand inverter communications, enabling compatibility with major solar inverters including Pylontech, Growatt, Deye, and more. Modular expansion allows up to 8 units to be connected in parallel, letting users scale capacity to meet growing energy needs without overhauls.

    Its Comprehensive Smart System elevates user experience with an intuitive interactive interface, full real-time monitoring and control, and integrated Wi-Fi modem support for OTA (Over-the-Air) online upgrades. This ensures convenient after-sales maintenance and keeps the system optimized with the latest firmware updates.

    Project

    Application Scenarios

    Our aim is to serve the global market through localized production and a global supply chain, helping customers achieve their carbon reduction goals.

    FAQ

    • What are the functions of Jitaiwa thin film solar power tiles?

      With the advantages of policy support, technological progress, market demand growth and perfect integration with architectural aesthetics, G-TILE will shine brightly in the field of energy transformation and construction, and become an important force to promote sustainable development.

    • What are the functions of Jitaiwa thin film solar power tiles?

      With the advantages of policy support, technological progress, market demand growth and perfect integration with architectural aesthetics, G-TILE will shine brightly in the field of energy transformation and construction, and become an important force to promote sustainable development.

    • What are the functions of Jitaiwa thin film solar power tiles?

      With the advantages of policy support, technological progress, market demand growth and perfect integration with architectural aesthetics, G-TILE will shine brightly in the field of energy transformation and construction, and become an important force to promote sustainable development.

    • What are the functions of Jitaiwa thin film solar power tiles?

      With the advantages of policy support, technological progress, market demand growth and perfect integration with architectural aesthetics, G-TILE will shine brightly in the field of energy transformation and construction, and become an important force to promote sustainable development.

    Tags:

  • Advanced Smart BMS
  • Indoor Solar Battery Storage
  • Residential ESS
